NocPix Bolt L35R Thermal Imaging Scope

The NocPix Bolt L35R thermal scope is the latest leap forward in precision thermal riflescope technology at an incredible price.

Equipped with a self developed thermal sensor with an NETD of sub 20mK with 50hz frame rate, ensuring high quality, smooth thermal imaging.

With an integrated 1200m laser rangefinder, offering both single and continuous ranging, it's comprehensive ballistic calculations, ensuring each shot is perfectly aligned, making target acquisition easier and more effective.

NocPix Bolt L35R – Redefining Thermal Imaging

The Next Level in Professional Thermal Imaging

Introducing the NocPix Bolt L35R — a cutting-edge thermal riflescope designed for professionals who demand exceptional clarity, accuracy, and reliability in the most challenging conditions.

Precision Thermal Performance
With 3.5x to 14x variable magnification the Bolt L35R thermal scope features a self-developed thermal sensor with a NETD of <20mK and a 50Hz refresh rate, delivering smooth, high-quality imaging with superb detail and contrast — even in adverse environments.

With 3.5x to 14x variable magnification,

Integrated 1200m Laser Rangefinder
The built-in laser rangefinder supports both single and continuous measurement modes, enabling fast and precise distance readings. Combined with comprehensive ballistic calculations, it ensures every shot is aligned for maximum accuracy and effectiveness.

Advanced 384x288 Thermal Sensor
The high-resolution thermal core offers excellent image clarity and target definition at extended distances. Its ultra-sensitive sensor detects even subtle temperature differences, enhancing target identification in both day and night scenarios.

High-Definition AMOLED Display
A crisp, high-contrast AMOLED screen provides a sharp and vivid viewing experience. This level of clarity supports faster target acquisition and improved situational awareness in the field.

35mm Germanium Lens with Manual Focus
The 35mm f/1.0 Germanium lens strikes the ideal balance between field of view and detection range. Manual focus allows users to dial in image sharpness, while premium optics deliver outstanding thermal transmission.

Ergonomic and Tactical Design
Styled after traditional daytime scopes, the Bolt L35R offers a familiar, intuitive user interface for professionals transitioning to thermal. Its rugged, IP67-rated construction ensures full protection against dust, rain, and immersion.

Recoil-Resistant and Multi-Calibre Compatible
Engineered to handle powerful platforms, the Bolt L35R is recoil-rated up to .375 H&H — making it a dependable choice across a wide range of calibres and shooting applications.

Core Specifications

• Thermal Sensor: 384x288 resolution, 12µm pixel pitch

• Sensor Sensitivity (NETD): ≤ 20mK

• Frame Rate: 50Hz for smooth image rendering

Optical Features

• Objective Lens: 35mm f/1.0 Germanium lens

• Magnification:

  • Base: Approx. 3.5x

  • Digital Zoom: 1x / 2x / 4x / 8x

• Field of View (H×V): ~12.5° x 10.0°

• Focus: Manual focus adjustment for precise clarity

Laser Rangefinder (LRF)

• Integrated LRF: Yes

• Range: Up to 1000 metres

• Accuracy: ±1 metre

Display & Output

• Display Type: High-contrast AMOLED

• Display Resolution: 1024x768

• Picture-in-Picture (PIP): Yes

• Reticle Options: Multiple, with colour and pattern selection

• Zeroing Profiles: Multiple weapon profiles supported

Imaging Modes

• Colour Palettes: Black Hot, White Hot, Red Hot, Fusion, and others

• Image Enhancement: Dynamic image sharpening, noise reduction

• Hot Spot Tracking: Yes (target heat signature locking)

Recording & Connectivity

• Video Recording: Onboard photo and video with sound

• Memory: Built-in storage (exact capacity TBC)

• WiFi Streaming: Supported, compatible with mobile app

• USB-C Port: For data transfer and charging

Power & Performance

• Battery Type: Rechargeable Li-ion battery pack

• Runtime: Up to 8 hours continuous use (depending on mode)

• External Power: USB power bank compatible

Durability & Mounting

• Housing Material: Aluminium alloy chassis with polymer external shell

• Waterproof Rating: IP67 (dustproof, waterproof, submersible to 1m)

• Recoil Resistance: Up to .375 H&H / 12-gauge

• Operating Temperature: -20°C to +50°C

• Mounting System: 30mm ring mount compatible

Dimensions & Weight

• Length: Approx. 330mm

• Weight: Approx. 950g (without mount)

Included in the Box

• NocPix Bolt L35R Thermal Riflescope

• Battery Pack and Charger

• Carry Case

• Lens Cleaning Cloth

• Instruction Manual
